Automatic Asphalt Mixture Blender TBT-F02-20

Item Code:TBT-F02-20 Features:
  • Description
  • Main Specifications
  • Accessories

1. This instrument adopts advanced microcomputer control technology. Temperature can be set from ambient to 200℃ at will and automatically adjusted by PID. The blending time can be controlled automatically. It achieves the automation for operation.

2. It has protecting function for phase sequence which can prevent the machine from damage because of phase sequence fault.

3. Floor type structure. Reasonable design and easy to use.



Blending amount

20L

Temperature control range

Room temperature~200℃

Temperature control accuracy

 ±5℃

Timing range

(0~999) s

Timing accuracy

 ±0.1s

Rotation rate of paddle

Complete revolution 47R/min, Autorotation 76R/min

Blending motor

Alternating current 380V, 550W;1400R/min;50Hz

Lifting motor

Alternating current 380V,250W;1400R/min;50Hz

Overall dimension

600mm×400mm×1300mm

Net weight

215Kg

Power supply

AC(380±10%)V;16A;50Hz(three-phase four-wire with null line)

Ambient temperature

(-5~+50)℃

Relative humidity

≤80%
