Engler Viscometer TBTWNE-1B

Item Code:TBTWNE-1B Features:
  • Description
  • Main Specifications
  • Accessories

1. The instrument adopts desktop, all-in-one and double inner crucible structure. Both of inner and outer crucibles adopt stainless materials. Inner crucible has been specially processed. The smooth finish corresponds with the test requirements.

2. The flow out time adopts digital display. Can do parallel determination for 2 samples at the same time. Easy to use and efficiency is high.

3. The temperature controller adopts digital display temperature controller with P,I,D position regulatory function. Easy to set the parameters and temperature controlling precision is high.



Power supply

AC(220±10%)V, 50Hz

Standard water value

(51±1)s

Temperature range

(0~100)℃



Temperature control accuracy

±0.1℃



Engler viscosity thermometer

Correspond with GB/T 514

Specification of measuring flask

(200±0.2) ml



Inner crucible

Stainless steel material

Timing

Max 999.9s



Timing mode

LED electronic timing

Heating power

700W

Ambient temperature

(-10~+40)℃



Relative humidity

≤85%

Dimension

430mm×410mm×620mm

Maximum power consumption

800W
