Force Gauge (SH series)

Enlarge

Item Code: Features:

CE approved
Neutral packing

Description
Main Specifications
Accessories

SH series Force Gauge

I. Product Trait:

High accuracy & High resolution: Accuracy : ±0.5% Min resolution : 0.001N;

Peak holding and auto-releasing function: Catching and holding the peak value in test, the peak holding time can be set(1-10 seconds);

Comparing function: Initial input of the tolerance limit(Max/Min)enables the device to judge the measured result as Go(Green pilot lamp)/NG(Red pilot lamp);

Units conversion: Converting three units(N, kgf, ibf) automatically;

Memory function: Memory 10 testing data, and calculate the average;

LCD screen direction turning function: Pressing the unit key for 3 seconds, the LCD screen will change its direction;

Automatic power off function: Power off time (1-60minutes) can be set by yourself;

RS-232C output: Transmitting the data to Printer or computer, saving it into "Excel" for analysis

II. Product Specification

Product model	SH-2	SH-5	SH-10	SH-20	SH-50	SH-100	SH-200	SH-500
Capacity	2N	5N	10N	20N	50N	100N	200N	500N
Load Resolution	0.001N	0.001N	0.005N	0.01N	0.01N	0.05N	0.1N	0.1N
Sensor Conformation	Sensor Inside
Measuring range	10%-100%FS
Inaccuracy	Within ±0.5%
Power	8.4V 1.2V*7 Nickel hydride battery
Charging time	About 4 hours
Operating time	About 40 hours
Waiting time	About 3 month
Battery life	≥300times
Adapter	Input: AC 220V 50Hz Output: DC 12V 300mA
Weight	About 0.9kg
