    Single-stage Vacuum Pump (RE)

    Single-stage Vacuum Pump (RE)
    Item Code: Features:
    • Description
    • Main Specifications
    • Accessories
    RE Single-stage Vacuum Pump
    Model
    RE-2
    RE-4
    RE-6
    RE-8A
    RE-12
    RE-14
    Voltage(V/Hz)
    220V/50Hz
    Bleed(L/S)
    2
    4
    6
    9
    12
    14

    CFM
    1.3
    2.3
    3.7
    5.3
    7
    8.5
    Max.pressure
    Pa
    10
    Microns
    75
    Power (W)
    1/5HP
    1/4HP
    1/4HP
    1/2HP
    1/2HP
    3/5HP
    Caliber dimension
    5/8''-18UNF
    7/16''-20UNF
    Oilconsumption（mL）
    125
    250
    300
    500
    550
    600
    Dimension（cm）
    27×17×20
    30×15×20
    34×15×20
    36×22×25
    36×15×25
    38×22×25
    Weight（kg）
    3.3
    5.2
    5.7
    11
    12
    12.5



    Any questions, please contact us.

    Email: sales@tbt-scietech.com;toni_gu@tbt-scietech.com

    Tel: 86-25-8472 1577/8472 1579/8472 1907
