Detecting System for Borehole Concrete Pile Manufacturer

Detecting System for Borehole Concrete Pile JJC-1EG

Item Code:JJC-1EG Features:Detecting System for Borehole Concrete Pile

Description
Referring Standard
Features
Technical Specification

JJC-1EG Detecting System for Borehole Concrete Pile is a kind of special equipment for detecting the pore-forming quality of bored piles. It goes through the development of JJC-1A, JJC-1B, JJC-1C and JJC-1D. It takes the construction environment and requirements on site into consideration, being easy for operation and having a higher accuracy.

This system is composed of model JJC-1EG control case, model JJY-6 caliper /inclinometer measuring probe, model JNC-2 sediment/inclinometer measuring probe, model JC-100 automatic cabling winch, pulley and so on.

Hole measuring range	Ф500mm～Ф1600mm
Hole measuring bias	≤±5mm
Verticality measurement	Measuring range: 0°～10° Resolution：0.01° Measuring bias：≤±0.1°
Sediment thickness measurement	Diameter of probe underground：Ф40mm Interval between electrodes：20mm±0.5mm Specific resistance measuring bias:≤5%
Winch	Length of cable：100m（as customer’s need） Pulling strength of cable：≥0.35t（tear-out strength 0.65t） Cabling speed:10m/min Depth indication bias：≤1‰ Weight of winch：50kg Motor power：550W Dimension（L×W×H）： 600mm×450mm×350mm，600mm height by hand Control mode：Two direction switch Cabling mode:It has automatic cabling function and hand cranking function.
Working temperature	Measuring probe： 0℃～50℃ Units on the ground： -10℃～45℃
Relative humidity	＜85%
Power supply	AC(220V±10%),50Hz

Detecting System for Borehole Concrete Pile JJC-1EG
