Screw diameter

20

Rotation speed of screw

0-95 rpm

Length ratio

1:28

Main Motor

2.2KW

Screw material

38CrMoAL chromium-molybdenum steel

Reduction Ratio

1:1.15

Volume   W×D×H

Around 1000*600*750mm

Power supply

AC380V, 3 phase

Die diameter

30

Air blowing

Compressed air 0-5bar

Air cooling

Air blower flow 20L/min

Traction roller size

60*300mm

Traction winding speed

0.5-2m/min

Max film folding diameter

100mm

Traction motor

50W

Winding torque motor

2.5N.m

Fan

0.15Kw

Dimension

600*556*1550mm

Power supply

AC380V, 3 phase

Weight

215kg
