Maximum Capacity

100KN

300KN

Relative Error

±1%

±1%

Rated pressure of oil pump

30Mpa

25Mpa

Diameter of bearer

Ф30 mm

Ф30 mm

Max. distance between upper and lower bearers

165 mm

165 mm

Central distance between upper bearers

150 mm

150 mm

Central distance between lower bearers

450 mm

450 mm

Platen dimension

Ф118 mm

Ф118 mm

Max. Vertical clearance between platen

180 mm

180 mm

Diameter of piston and maximum travel of piston

Ф125 mm x 80 mm

Ф125 mm x 80 mm
