    Portable Measuring Microscope (XC Series)

    Portable Measuring Microscope (XC Series)
    Item Code: Features:
    Neutral packing
    OEM accepted
    • Description
    • Main Specifications
    • Accessories
    XC Series Portable Measuring Microscope
    Specification:




    XC-100L
    XC-50L
    XC-40L
    XC-20L
    Total Magnification
    100×
    50×
    40×
    20×
    Mechanical Tube Length
    160mm
    Eyepiece
    10×
    Objective
    10×
    5×
    4×
    2×
    Numerical Aperture
    0.25
    0.12
    0.1
    0.05
    Diameter of Viewing field in Eyepiece
    φ18mm
    Eyepiece Reticle
    0.1mm
    Fine Division
    0.01mm
    0.02mm
    0.025mm
    0.05mm
    Working Distance
    6.93mm
    17.6mm
    18mm
    17.2mm
    Focus Range
    30mm
    Diameter of Bearing Plane
    φ63mm
    Height of Microscope
    210mm
    Mass of Microscope
    650g
    Illumination
    Pen light, No.7 battery

    　
    XC-100
    XC-60
    XC-40
    XC-20
    XC-100L
    XC-60L
    XC-40L
    XC-20L
    Eyepiece10×/
    Cross with Reticle
    ●
    ●
    ●
    ●
    ●
    ●
    ●
    ●
    Objective10×
    ●



    ●



    Objective5×

    ●



    ●


    Objective4×


    ●



    ●

    Objective2×



    ●



    ●
    Pen Light Illumination
    (with holder)




    ●
    ●
    ●
    ●
    Note: ●Standard Outfit, ○Optional


    Any questions, please contact us.

    Email: sales@tbt-scietech.com;toni_gu@tbt-scietech.com

    Tel: 86-25-8472 1577/8472 1579/8472 1907
