Model
|
9023A(AD)
|
9053A(AD)
|
9123A(AD)
|
9203A(AD)
|
Chamber volume
|
24.7L
|
51.4L
|
105.8L
|
198L
|
Main voltage
|
220V 50Hz
|
Temperature control range
|
Ambient Temp. +10℃ - 200℃
|
Temperature fluctuation
|
±1℃
|
Dimension of working chamber
|
300 x 300 x 275
|
420 x 350 x 350
|
550 x 350 x 550
|
600 x 550 x 600
|
Outside dimension
|
580 x 470 x 445
|
710 x 520 x 520
|
830 x 530 x 720
|
880 x 740 x 790
|
Net weight
|
30kg
|
43kg
|
59kg
|
77kg
|
Comsuption power
|
500W
|
740W
|
1240W
|
1640W
|
Shelf dimension
|
246 x 280
|
366 x 340
|
496 x 340
|
546 x 540
|
Shelves(supply/most)
|
2/4
|
2/7
|
2/12
|
2/9
|
* Dimension unit: mm, AD means programmable 10 bands temp. control.
|
