Detection System for Bored Pile Manufacturer

1. It adopts PC technology and special software to real-time display and process the data and curve. It can make the detection report rapidly.

2. The detection is accurate. Easy to use and working efficiency is high.

Borehole detection range
Standard configuration	Ф500mm～Ф1600mm（JJY-2）
Users can select	A. Install a 200mm extending leg on the detection leg to expand the detection range to Ф2000mm on base of standard configuration.
	Ф1500mm～Ф2500mm（JJY-5）
	C. Install a 770mm extending leg on the detection leg to expand the detection range to Ф2800mm on base of B.
Bias of borehole detection	±15mm（JJY-2）, ±25mm（JJY-5）
Electric current supply for borehole diameter detecting probe	10mA
Sensitivity of borehole diameter detecting probe	≥100mV/10cm (When the electric current supply is 10mA)
Cable length	100m(125m is optional, maximum)
It has standard format of detection report for selection.
The notebook PC can meet requirement for saving data
Note: (1) Equipped with quick report and inspection report standard formats for selection. (2)Notebook PC is provided by you.
