Marshall Compacter (Economic Type) Manufacturer

Marshall Compacter (Economic Type) TBTMJS-0702

Item Code:TBTMJS-0702 Features:

Description
Main Specifications
Accessories

TBTMJS-0702 is made for preparing specimen which used to do marshall stability test.

It is a standard compactor for forming cylinder specimen of D101.6mm or D152.4mm used in standard Marshall test and indirect tensile test (split method).

Hammer weight(small)	4536g±9g
Falling of Hammer	457mm±1.5mm
Mould(small)	D101.6mm (TBTMJS-0702B) D101.6mm,D152.4mm (TBTMJS-0702A)
Compaction speed	(60±5)times/min
Compaction time	(0～999)times
Power supply	220VAC 50HZ (60HZ optional)
Dimension	1740mm×540mm×540mm
Weight	Around 180kg

TIPS:TBTMJS-0702A(D101.6mm and D152.4mm)

TBTMJS-0702B(D101.6mm)
