XSZ-148 Research Biological Microscope
I .Application:
High efficiency, flexibility and stability are the characters of this series microscope. It is specially developed for various applied scopes. It is widely used, from daily work to scientific research, in Laboratory, Hospitals and Colleges. Because of higher capability with lower price and humanized configuration design, It also becomes the first choice of individual, Schools, and Scientific research organization.
II. Features:
1. Wide-field Eyepiece, high light illumination and superior optical parts make the image clear, sharp and bright.
2. Backward nosepiece with superior objectives makes the best viewing effect and more space for the operator.
3. Wide mechanical stage with 2-Microslide specimen clamp provides more convenience for the observer.
4. High precision focusing adjustment system and humanized configuration design provide operator more comfortable.
5. Frontal undrawing type Light collector framework, makes the user change the bulb more quickly and easily
III. Specification
Specification
|
Model
|
XSZ-148
|
XSZ-148T
|
Viewing head
|
Compensation Free
Binocular Head.
Inclined at 3 0 °
( 55mm -75mm )
|
●
|
|
Compensation Free
Trinocular Head.
Inclined at 3 0 °
( 55mm -75mm )
|
|
●
|
Eyepiece
|
WF10 ×
|
●
|
●
|
Objective
|
Achromatic objective:
4x, 10x, 40x(S), 100 x (S) Oil
|
●
|
●
|
Stage
|
Double layers mechanical stage
|
●
|
●
|
Stage size: 180mm × 150mm
|
Moving range: 75mm x 50mm
|
Condenser
|
N.A1.25 Abbe condenser
with iris diaphragm&filter
|
●
|
●
|
Focusing
|
Coaxial coarse & fine focusing
adjustment with rack
And pinion mechanism
|
●
|
●
|
Fine focusing scale
Value 0.002mm
|
Collector
|
High brightness Kohler
illumination
|
●
|
●
|
Light source
|
Halogen tungsten bulb
12V/20W.AC 85V-230V
|
●
|
●
|
Adjustable brightness
|
Optional
Accessory
|
Eyepieces:
|
WF16x,WF20x,P16x 1.3 Mega pixels
CMOS electronic
eyepieces
|
Plan-Objectives:
|
4X,10X,20X(S),40(S),
60X(S), 100(S)Oil
|
Semi-plan objectives:
|
4X,10X,20X(S),40(S),
60X(S), 100(S)Oil
|
Infinite Objectives:
|
4X,10X,20X,40X(S),
60X,100(S)Oil
|
Others
|
Phase contrast
Attachment
|
Photo and CCD
attachment
|
Mark” ● ”standard outfit. Mark:” ○ ”optional parts.
|
