Portable Digital Inclinometer Manufacturer

1. Using high-precision gravity accelerometer and three-dimensional magneto-resistive sensors measuring instrument system, the sensitivity is high, the repeatability is good, and the volume is small.

2. Using modern digital signal processing technology, to accurately calculate angle and azimuth, the measurement results to achieve high precision requirements.

3. The application of modern communication coding technology, long cable digital signal reliable transmission, improves the anti-interference ability of the instrument.

4. The inclinometer probe canceled hammer swing member, the instrument greatly improve seismic performance; actual measured depth interval point and measuring points can be arbitrarily chosen, improve measurement efficiency.

5. Using the high brightness LCD graphical display mode, the control unit by 6 control keys to complete the man-machine interactive operation, the measurement data stored automatically recorded, without human intervention.

6. The keyboard and display community physiognomy combined, easier to use, buy mini-printers, can also carry out on-site printing inclinometer results.

Inclinometer depth	≤1200 m
Parameter measurement range and accuracy
angle measuring range	0 ~ 50 °
measurement accuracy	± 0.2 °
When the angle 1 ~ 3 °: measurement error: ± 5.0 °
When the apex angle of 3 ~ 50 °, the measurement error: ± 3.0 °
Measurement: measuring point, the measuring point and the measured depth interval points arbitrarily determined
Data storage	the maximum 100 sets of measurement data
Power Supply	AC 220V ± 10%, 50Hz
Ground control unit working environment	temperature: -10 ℃ ~ 50 ℃
	Relative humidity: ≤85%
Inclinometer probe Working Environment: Temperature	Temperature: 0 ℃ ~ 55 ℃
	Pressure: ≤15MPa
Ground control unit Dimensions	270 × 220 × 155 (mm)
	Weight: 2.4 (kg)
Inclinometer probe Dimensions	Φ40 × 1600 (mm); Weight: 10 (kg).

Portable Digital Inclinometer KXP-3A2
