Compression Testing Machine with Digital Display TBTCTM-12000

Item Code:TBTCTM-12000 Features:
  • Description
  • Referring Standard
  • Features
  • Technical Specification

The testing machine is designed for testing the compressive strength of building materials such as brick, cement mortar and concrete; it is electro-hydraulically powered and the pressure applied on the specimen can be displayed directly; The maximum force value can be maintained and the data measured can be saved when the power is off; The test data can be processed automatically and the test report can be printed



Maximum Capacity:

12000 kN

Measuring Range

0-12000 kN

Relative Error

±1%

Platen dimension

790mm×900 mm

Max. Vertical clearance between platen

1500 mm

Maximum travel of piston

120 mm

Diameter of piston

Ф630 mm

Power supply

220VAC 750W
