Universal Testing Machine with dial gauge(analog type) TBTUTM-1000D(WA-1000D)

Item Code:TBTUTM-1000D(WA-1000D) Features:
  • Description
  • Main Specifications
  • Accessories

Used for performance of tensile, compression, flexure for metal material, concrete, brick, cement and other construction material;

The big dial gauge make it easy for result reading; And as it’s mechanical dial gauge, in some countries with high temp. or high humidity, this is most popular type;

Max Capacity (kN)

1000

Measuring Range (kN)

0 ~ 200 , 0 ~ 500, 0 ~ 1000

Accuracy (from 20% of the full testing range)

Grade 1

Time for Load Maintained (s)

≥ 30s

Max. distance between flexible clips (including ram travel)

500

Distance between upper and lower platens

0 ~ 600

Distance between two fulcrums of bending test

100 ~ 420

Cliping diameter for round specimen

Φ20 ~Φ60

Cliping thickness for flat specimen

0 ~ 40

Max. ram travel (mm)

200

Max rising speed of the ram (without load mm/min)

0 ~ 80

Dimensions (L*W* H)

Main frame (mm*mm*mm)

960*620*2150



Console (mm*mm*mm)

600*660*1780

Net Weight (Kg)

Main frame

2200



Console

400



1. O-ring

2. Oil flow control valve

3. Oil return valve

4. Oil pump

5. Motor
