BA2000i Series Biological Microscope
|
Description:
|
|
Total magnifications .....................................40X-1600X
Eyepieces ...........................................WF10X(FN 20)
IOS infinity-corrected plan achromatic objectives
..PL 10X/0.25 PL 20X/0.40 PL 40X/0.66 PL 100X/1.25(Oil)
Condenser .......................................................NA1.25
Field iris
Note: IOS= Infinity-corrected optical system
Optional accessories
1) Eyepieces ............................WF10X( pointer) WF16X
2) IOS infinity-corrected plan arochmatic objectives
.................................................................. PL 4X/0.10
3) IOS infinity-corrected plan phase contrast attachment
4) Dark field condenser ...............................NA0.83-0.91
5) Polarizer slide
6) Analyzer slide
7) 35mm photo attachment
............................... Photo eyepieces S2.5X S4X S6.3X
................................................... 10X reticule eyepiece
8) C-Mount and CCD camera
9) Transmitted-reflect-light attachment
................................................. 6V 20W halogen lamp
10) Side viewing attachment
BA2000i Series Biological Microscope Standard Outfits
|
Items
|
Spec.and Parameter
|
BA2203i
|
BA2303i
|
Order No.
|
|
Eyepiece
|
10X-20
|
●●
|
●●
|
EW10
|
|
ISO Plan
Achromat
Objetives
|
Plan 10X/0.25
|
●
|
●
|
B-OPi10a
|
|
Plan 20X/0.40
|
●
|
●
|
B-OPi20a
|
|
Plan 40X/0.66
|
●
|
●
|
B-OPi40a
|
|
Plan 100X/1.25(Oil)
|
●
|
●
|
B-OPoi100a
|
|
Main Body
|
Quintuple Nosepiece
|
●
|
●
|
A08a
|
|
Seidentopf
Binocular Head
|
|
●
|
|
TBR11
|
|
Seidentopf
Trinocular Head
|
|
|
●
|
TTR04
|
|
Mechanical
Stage
|
Moving Range:76×50
Size:160×135
|
●
|
●
|
S26
|
|
Condenser
Focusing Team
|
Rack and Pinion
Fpcusing Mechanism
|
●
|
●
|
CA03a
|
|
Condenser
|
N.A. 1.25
|
|
|
C23
|
|
Field Diaphragm
|
￠2-￠35
|
●
|
●
|
DI06
|
|
Immersion Oil
|
|
●
|
●
|
|
|
Filter
|
￠32 (Blue)
|
●
|
●
|
CU2-1
|
BA2000i Series Optional Accessories
|
Items
|
Spec and Parameter
|
Order No.
|
|
Eyepieces
|
10X-18 (Pointer)
|
Erg10
|
|
16X-10
|
EP16a
|
|
16X-14
|
EW16
|
|
IOS Plan Achromat Objective
|
Plan 4X/0.10
|
B-OPi4a
|
|
Phase Contrast
Attachment
|
IOS Plan
Positive Ph.
Objectives
|
Plan ph10x/0.25
|
B-OPip10a
|
|
Plan ph20x/0.40
|
B-OPip20a
|
|
Plan ph40x/0.66
|
B-OPip40a
|
|
Plan ph100x/1.25(Oil)
|
B-OPoip100a
|
|
IOS Plan
Negative Ph.
Objectives
|
Plan ph10x/0.25
|
B-OPin10
|
|
Plan ph20x/0.40
|
B-OPin20
|
|
Plan ph40x/0.66
|
B-OPin40
|
|
Plan ph100x/1.25(Oil)
|
B-Opoin100
|
|
Phase Contrast Condenser
|
C22
|
|
Centering Eyepiece
|
ECi
|
|
Dark Field
Attachment
|
Dark Field Condenser
(N.A. 0.83-0.91)
|
C07
|
|
Polarizing Attachment
|
Polarizer Slide
|
PO01
|
|
Analyzer Slide
|
PA01
|
|
Photo Attachment
|
10X Reticle Eyepiece
|
EPr10b
|
|
2.5X Photo Eyepiece
|
EPHn2.5
|
|
4X Photo Eyepiece
|
EPHn4
|
|
6.3X Photo Eyepiece
|
EPHn6.3
|
|
135 Photo Device (With 4x Photo Eyepiece)
|
MP03
|
|
TV and Video
Attachment
|
C-mount Adaptor、Color or Black and
White Monitor、CCD Camera
|
TV02
|
|
Epi-illumination
Attachment
|
6V20W Halogen Tungsten Lamp
(With Reflector)
|
H09
|
|
Side Viewing
Attachment
|
Two View Field Space 600mm
|
TB06
|
|
Projection Attachment
|
|
PJ04
|
|
Filter
|
￠32 (Green、Amber)
|
CU02-2、3
|
|
Image Analyis and
Disposal System
|
|
|
Note：“●”in the table is standard attachment. “○”is optional accessories.
Design change:To keep pace with technological advance ,we have reserved
the right to make design modifications and changes without notice.
|
