Triaxial Force

2000kn

Effective Measuring Range

40~2000kn

Measuring Resolution

20n

Measuring Accuracy

±1%

Confining Pressure

100mpa Max.

Confining Pressure Resolution

0.1mpa

Rock Specimen Size

d50*100

Deformation Range

Axial 0~5mm / Radial 0~3mm

Deformation Measuring Resolution / Accuracy

0.0001mm / 1%

Deformation Speed Control Range

0.01~50mm/Min.

Displacement Measuring Range

0~100mm

Displacement Accuracy / Resolution

<±0.5%Fs /  >0.0001

Pore Pressure

40mpa Max.

Effective Pressure Range

4%~100% f.s

Pore Pressure Measuring Resolution

≤±2%

Water Storage

>500ml

Specimen Size

d100*200mm / d75*150mm / d50*100mm / d25*50mm

Advantages

1. With Servo Control

2. Loading & Unloading Time Range: 0~30hour

3. With Over Limit Protection
